실내 인체 존재 감지 레이더 모듈 ASX02

실내 인체 존재 감지 레이더 모듈 ASX02

모델:ASX02

Functions:Presence Detection, Target Distance,
Movement Direction, Gesture Control

Modulation Mode:FMCW

Transmit Frequency:24GHz

Transceiver Channel:1TX/ 1RX

Powered by:5V DC / 1A

Detection Distance:0.5 ~ 2.5m (1.6 ~ 8.2ft)

Beamwidth (방위각):-40°~40°

Beamwidth (pitch):-20°~20°

Communication interface:UART

전력 소비:＜0.5W

Dimensions (L*W):39*29mm (1.5*1.1~에)

Module Weight:4g

문의 보내기

제품 세부 정보

ASX02, ASX08 and ASX10 series are mmWave radar modules that are ideal for applications such as indoor human body presence detection and tracking. Featured by designs of FMCW modulation with high complexity and performance, along with advanced radar algorithm accompanied by deep machine learning, this line of radar modules provides excel user experiences in applications such as smart toilets, smart lighting, smart screen control, and so on. It provides a budget replacement of current technologies such as PIR and doppler radars.

Functions	Presence Detection, Target Distance, Movement Direction, Gesture Control
Modulation Mode	FMCW
Transmit Frequency	24GHz
Transceiver Channel	1TX/ 1RX
Powered by	5V DC / 1A
Detection Distance	0.5~2.5m (1.6~8.2ft)
Beamwidth (방위각)	-40°~40°
Beamwidth (pitch)	-20°~20°
Communication interface	UART
전력 소비	＜0.5W
*Dimensions (LW)**	3929mm (1.51.1~에)
Module Weight	4g
